Separate Temperatures for Day and Night

Two different temperature cycles can be set for day and night according to the 24-hour physiological needs of animals and plants.

Dual Relay & Double Sockets

1 relay for control and another for protection. Supports 2 heaters at a time, max 100~240V AC 50/60Hz, heating mode only.

Dual Display Screen

Display measured temperature and target temperature at the same time for easier temperature monitoring.

Early Warning System

Alarms to detect over-temperature and sensor faults, safer for monitored creatures and plants, and better for longer device lifetime.

Seed Germination
Fungus Fermenting
Pets Breeding
Hatching

Product Overview



Specs

Model:

ITC-306T

ITC-306T-WiFi

Power Input:
100 ~ 240V AC, 50Hz/60Hz
100 ~ 240V AC, 50Hz/60Hz
Temp Control Output:
Max. 10A, 100V ~ 240V AC
Max. 10A, 100V ~ 240V AC
Relay Contact Capacity:
Heating (10A, 100 ~ 240V AC)
Heating (10A, 100 ~ 240V AC)
Temperature Control Range:
-58 ~ 210℉/ -50 ~ 99℃
-58 ~ 210℉/ -50 ~ 99℃
Temp Control Accuracy:
±1℉(-58 ~ 160℉) / ±1℃(-50 ~ 70℃)
±1℉(-58 ~ 160℉) / ±1℃(-50 ~ 70℃)
Temp Control Mode:
On/Off Control, Heating
On/Off Control, Heating
Sensor Type:
NTC sensor
NTC sensor
Sensor Length:
6.56ft / 2m
6.56ft / 2m
Body Dimension:
5.5x2.7x1.3 inches (140x68x33mm)
5.5x2.7x1.3 inches (140x68x33mm)
Socket Dimension:
US: 3.3x1.7x1inches (85x42x24mm), EU: 5.3x2.1x1.6 inches (135x54x40mm), UK: 5.5x2.0x1.1 inches (140x51x27mm)
US: 3.3x1.7x1inches (85x42x24mm), EU: 5.3x2.1x1.6 inches (135x54x40mm), UK: 5.5x2.0x1.1 inches (140x51x27mm)
Input Power Cable Length:
5ft / 1.5m
5ft / 1.5m
Output Power Cable Length:
1ft / 30cm
1ft / 30cm
Ambient Temp:
-22℉~ 167℉/ -30℃~ 75℃
-4℉~ 104℉/-20℃~ 40℃
Storage Temp:
-22℉~ 167℉- /30℃~ 75℃
32℉~ 140℉/0℃~ 60℃
Storage Humidity:
20 ~ 85%RH
20 ~ 80%RH
Warranty:

1 Year

1 Year

Show More

Compare with Others

Appearance:

Temperature Controller ITC - 306T Series - INKBIRD Temperature Controller ITC - 308 Series - INKBIRD Aquarium Temperature Controller Series - INKBIRD
Model:

ITC-306T

ITC-308

ITC-306A

WiFi: WiFi Version Available WiFi Version Available
Heating:
Cooling: x x
Probe Type: NTC NTC Plastic
Probe Quantity: 1 1 2
Temp Control Range: -58 ~ 210℉/ -50 ~ 99℃ -58 ~ 248℉/ -50 ~ 120℃ 68 ~ 95℉/ 20 ~ 35℃
Temp Measurement Range: -58 ~ 210℉/ -50 ~ 99℃ -58 ~ 248℉/ -50 ~ 120℃ -40 ~ 212℉/ -40 ~ 100℃
Temp Alarm: Only High High & Low High & Low
Probe Connection:

Intergrated

Intergrated

Intergrated



Frequently Asked Questions

Is ITC-306T waterproof?

The probe of ITC-306T is IP67 waterproof, but the body and socket are not. When used in a humid environment, it is recommended to use a silicone tube/heat shrink tube to protect the connection between the probe and the cable.

Can ITC-306T control both heating and cooling devices?

No, the ITC-306T can only control heating devices with a maximum current load of 10A at 120~240V AC.

Can I set multiple temperature settings on ITC-306T?

Yes, the ITC-306T allows you to set two different temperature setpoints, which is useful for applications where you need to maintain a specific temperature range with a different setpoint for day and night.

How to customize alarms on ITC-306T?

This temperature controller does not have custom alarm settings, instead offering sensor fault and over-temperature alarms for temperature below -58℉/-50℃ or above 210℉/99℃.
